Semi Automatic STRAPPING MACHINE

Our Semi Automatic Strapping Machine is designed for one touch easy operation, the instant heating method starts within 20 seconds with energy saving mode which automatically activates within 15 seconds of non – operation thus ensuring lesser breakdown and better longevity of the machine.

Lift type table-top option allows easy maintenance; intelligent controls in PCB can isolate malfunctioning and reduce time for repairs

Advantages/Features of Semi Automatic Strapping machine

-User Friendly , Easy apply Straps on Carton
-Ready to operate in a few seconds
-Heat Seals the straps
-High Quality Auto CutterLight in Weight
-Use less Space (Can accommodate anywhere)

Model

MPS-001SH

Strap Cycle Speed

1.5 sec./ strap (30 - 40 Straps/min.)

Tension Strength

15~60Kg

Table Height

750mm (001SH) & 380 mm (002LTH)

Strap Width

5~15mm (Adjustable)

Sealing Method

Heat Sealed

Minimum Strapping Size

60 mm (W) x 30 mm (H)

Maximum Strapping Size

Not Stipulated

Driving Motor

1 Ø 220V 200W

Power Supply

1 Ø 220V 50 Hz 350 W

Dimensions (mm)

900(W) x 580(D) x 750(H)

Weight

110Kg

MPS-001SH

MPS-001S

Model

MPS-001S

Strap Cycle Speed

1.5 sec./ strap (30 - 40 Straps/min.)

Tension Strength

5~50Kg

Table Height

740mm (001S) & 380 mm (002LT)

Strap Width

6~15mm (Adjustable)

Sealing Method

Heat Sealed

Minimum Strapping Size

60 mm (W) x 30 mm (H)

Maximum Strapping Size

Not Stipulated

Driving Motor

1 Ø 220V 200W

Power Supply

1 Ø 220V 50 Hz 400 W

Dimensions (mm)

895(W) x 565(D) x 740(H)

Weight

85Kg

Strap Cycle Speed

1.5 sec./ strap (30 - 40 Straps/min.)

Tension Strength

5~50Kg

Table Height

740mm (001S) & 380 mm (002LT)

Strap Width

6~15mm (Adjustable)

Sealing Method

Heat Sealed

Minimum Strapping Size

60 mm (W) x 30 mm (H)

Maximum Strapping Size

Not Stipulated

Driving Motor

1 Ø 220V 200W

Power Supply

1 Ø 220V 50 Hz 400 W

Dimensions (mm)

895(W) x 565(D) x 740(H)

Weight

85 Kgs.

MPS-001S

Strap Cycle Speed

1.8 sec./ strap (20 - 30 Straps/min.)

Tension Strength

5~50Kg

Table Height

740mm

Strap Width

6~15mm (Adjustable)

Sealing Method

Heat Sealed

Minimum Strapping Size

60 mm (W) x 30 mm (H)

Maximum Strapping Size

Not Stipulated

Driving Motor

1 Ø 220V 200W - Aluminium

Power Supply

1 Ø 220V 50 Hz 400 W

Dimensions (mm)

895(W) x 565(D) x 740(H)

Weight

85 Kgs.

MPS-001SE
