Millenium Packaging

Stretch Wrapping Machine

A stretch wrapping machine is a device used to wrap products with stretch film to secure and
protect them for transport or storage. Stretch wrapping is widely used in various industries for
packaging Carton boxes, pallets etc. keeping them stable, dust-free, and tamper-resistant. The
stretch film is highly elastic, and when applied under tension, it clings tightly to the product, forming
a secure wrap.

Advantages/Features of Semi Automatic Strapping machine


-User Friendly , Easy apply Straps on Carton
-Ready to operate in a few seconds
-Heat Seals the straps
-High Quality Auto CutterLight in Weight
-Use less Space (Can accommodate anywhere)

Model

W-090-SWBW (B)

Turn Table Dia

400 X 400 mm

TT Speed

3-20 RPM

Max. Roll Width

500 mm

Packing Height

500 mm

Max. Package Size

500mm X 500mm X 500mm

Weight Capacity

60 Kgs (Max)

Power Consumption

500W

Model

W-090-SWBW (B)

Turn Table Dia

400 X 400 mm

TT Speed

3-12 RPM

Max. Roll Width

500 mm

Packing Height

500 mm

Power Pre Stretch Unit

0-250% : 300% (optional)

Max. Package Size

500mm X 500mm X 500mm

Weight Capacity

80 Kgs (Max)

Power Consumption

750W

Model

W-090-SWBW (B)

Turn Table Dia

400 X 400 mm

TT Speed

3-12 RPM

Max. Roll Width

500 mm

Packing Height

500 mm

Power Pre Stretch Unit

0-250% : 300% (optional)

Max. Package Size

500mm X 500mm X 500mm

Weight Capacity

80 Kgs (Max)

Power Consumption

750W

Compressed Air

6 Bars

Model

W-090-SWBW (B)

Turn Table Dia

400 X 400 mm

TT Speed

3-12 RPM

Max. Roll Width

500 mm

Packing Height

500 mm

Power Pre Stretch Unit

0-250% : 300% (optional)

Max. Package Size

500mm X 500mm X 500mm

Weight Capacity

80 Kgs (Max)

Power Consumption

750W

Compressed Air

6 Bars

Model

MPS-W-090-SWRT

Maximum wrapping speed

15-25 loads/hour

Max Wrapping Height & Weight

2400mm / 2000KG

Turntable Speed

0-13RPM(Adjustable)

Turntable Size

1650mm

Turntable Drive

0.75PH Chain Drive

Cut Film

Automatic

Machine Size

L:2800mm W:1800mm H:2650mm

Machine Weight

800KG

Standard Pre-Stretch

300% pre-stretch

Film Capacity

250mm Diameter

Standard Film Width

500mm

Film Delivery System

Power Pre -Stretch
